Nikon announced the AF-S Nikkor 300 mm f/4E PF ED VR lens in early 2015. An update of AF-S Nikkor 300 mm f/4D IF-ED lens after a long time which was released back in 2000. The old master was renowned for its optical performance and still a highly regarded lens. So all of us anxiously waiting to see how the new kid out perform the old one and by what margin.

After the initial release some users pointed out the lens has issues with Vibration Reduction performance. In March 2015 Nikon acknowledged the issue and released a service advisory stating that they will fix the affected models and lens with serial number of 205101 or later has already been updated.

The key feature AF-S Nikkor 300 mm f/4E PF ED VR lens has is its compact size & weight. Besides the incorporation of 4.5 stop VR is something Nikon users were cravings for a long time.

I have been using the old AF-S Nikkor 300 mm f/4D IF-ED lens for quite sometime. As a result I know what are areas Nikon needed to update. Optically the old lens is very good, but it weighs 1.5 kg and has no VR. Using the lens handheld for long hours and in early morning is very difficult. Nikon fulfilled both the issues in a way beyond my expectation.

Construction
I really loved the compact size of the new PF lens. The plastic body is sturdy enough to give a solid feel. It's made in China like an iPhone. The shape of the lens is good for hand holding. Focusing ring and lens control switches are well placed. White lens mounting mark is prominent, which is easy to find out. The lens mount has rubber gasket for weather sealing. As an "E" series lens it has no aperture control lever in rear end.

Left : AF-S Nikkor 300mm f/4E PF ED VR   |  Right : AF-S Nikkor 16-35mm f/4G ED VR

The plastic lens hood HB-73 has a bayonet mount. Front end of the lens has a protective soft rubber ring. The 77 mm filter thread is buried inside which makes it little difficult to screw in the UV filter. You can clearly see the difference in filter thread placement in following images.

Filter Attachment thread : AF-S Nikkor 300 mm f/4D IF-ED



Filter Attachment thread : AF-S Nikkor 300mm f/4E PF ED VR

Nikon kept the Tripod collar ring RT-1 as an optional purchase. While using the lens I never felt the need of a tripod collar. My camera body with vertical grip weighs more than a kilo which counter balance the lens easily. Most standard professional lenses that weighs less than a kilo don't need a tripod collar. The tripod collar ring may be a helpful for light weight body like Nikon D5500 or D3300.

The major improvement Nikon did with this lens is the addition of Phase Fresnel (PF) lens elements. According to Nikon - "The PF lens element is based upon the Phase Fresnel lens, which appears to have a series of concentric circles engraved onto it."

The Phase Fresnel element is not normally visible. But you can see this glass element from certain angle relative to direction of light source. It helped Nikon to reduce the number of glass elements used in the lens resulting in a lightweight and compact lens.

Auto Focus Performance
Now a days auto focus is something that is available even in the cheap mobile phones. But for a prime lens like this we need something more than ordinary. In a sunny environment any lens can lock on to its subject easily. The real test is when situation gets tricky. For example I shoot a lot time in sub tropical forest. Shooting birds in the shade of big trees and sun peeping through the leaves makes focusing a lot difficult. The image below shows a condition where the black crested bulbul came for a few seconds before it fly away. I didn't get the chance to fix the exposure to match the lighting condition and sun was shinning right behind the bird.

Otherwise I was shooting in a dark environment like below.

I felt the auto focus performance of this lens has not improved. The focusing speed is equal to that of old AF-S Nikkor 300 mm f/4D IF-ED lens. Which is not quick enough for a modern lens. The lens can focus easily in good lighting condition but in the forest it was fumbling. I had to manually override the lens a lot of time to lock on to subject. Good thing is the focusing ring is well dampened, so its easy to focus manually. Here is test that shows focusing speed compared to the older model with and without Nikon AF-S Teleconverter TC-14E II. I used Nikon D700 body and lens cap was on.
